Browse Our Selection of 125 Open Dies Below – MOQ: 1000 kg Per Shape

Below are 125 open dies available for extrusion without tooling costs. Please note that we carry no stock of these extrusions and they are produced in mill quantities only, starting from 1000 kg per shape. If you are interested in a quote, reach out to us with the section number, desired quantity, and any requirements you have. If you have a custom aluminum extrusion shape, you can contact us for a quote as well. If you have any questions or would like a downloadable version, feel free to contact us and we will get back to you.

Extrusion Sections

Click an image to zoom in.

SL. No.Section No.AWeight kg/m
1193820.410.061
2193660.490.071
3193610.530.078
4193520.700.096
5193700.800.109
6193600.900.124
7193771.200.154
SL. No.Section No.ABCWeight kg/m
1193683.070.577.500.137
2193673.270.777.500.161
3193803.751.218.000.216
SL. No.Section No.ABCWeight kg/m
1193683.070.577.500.137
2193673.270.777.500.161
3193803.751.218.000.216
SL. No.Section No.AWeight kg/m
1193820.410.061
2193660.490.071
3193610.530.078
4193520.700.096
5193700.800.109
6193600.900.124
7193771.200.154
SL. No.Section No.AWeight kg/m
1193921.110.224
2193911.600.289
SL. No.Section No.AWeight kg/m
1194209.000.132
21941915.000.148
SL. No.Section No.AWeight kg/m
11944617.700.133
21945719.700.137
